Modern, powerful and free interface to the Fast Field Solvers
The ElectroMagnetic Workbench offers a full GUI-based 3D modeling interface for FastHenry. The workbench is based on FreeCAD, a parametric 3D CAD modeler. Parametric modeling allows you to easily modify your design by going back into your model history and changing its parameters. FreeCAD is open-source, multi-platform and highly customizable, scriptable and extensible.
The ElectroMagnetic Workbench is still being further extended to cover also the other Solvers, to offer a modern, powerful and free
front-end and back-end interface for the Fast Field Solvers.
The FreeCAD ElectroMagnetic Workbench add-on code is available from our download section.
Our premium 3D and 2D multi-platform parallel capacitance field solverFasterCap is a powerful three- and two-dimensional capactiance extraction program.
Windows porting of the well-known 3D capacitance solver FastCapFastCap2 is a software for computing the self and mutual capacitances of conductive three-dimensional structures embedded in a dielectric. The dielectric can be homogeneous or inhomogeneous.
Windows porting of the well-known 3D inductance/resistance field solver FastHenryFastHenry2 is a software for computing the frequency-dependant self and mutual inductances and resistances of a generic tridimensional conductive structure, in the magnetoquasistatic approximation. It can also generate Spice-compatible, multiple-frequency equivalent-circuit models.
Windows 3D viewer and text editor for FastCap2, FasterCap and FastHenry2 filesFastModel is our 3D viewer and text editor for FasterCap, FastCap2 and FastHenry2 files.
Voxel-based, MQS impedance solver.VoxHenry is a magnetoquasistatic (MQS) inductance extraction simulator for voxelized geometries. It is under some regards similar to FastHenry, as it can extract inductance and resistance values, but it is based on voxels, that are the 3D equivalent of the 2D pixels (simply put, voxels are 3D cubes). VoxHenry can handle a huge number of voxels, and has advantages over FastHenry when dealing with conductive structures that are not inherently long and thin (as FastHenry segments are).
Surface-based, wide bandwidth, fast field solver.FastImp is a program for accurate analysis of wide-band (full-wave) electromagnetic effects in very complicated geometries of conductors. It is based on a surface formulation, therefore the geometries are defined only through surface panels, making it easy to describe arbitrary shapes.
